Schubert & Salzer Type 8049-ExPro-FM Digital Positioner

Schubert & Salzer – Type 8049-ExPro Digital Positioner

Need help selecting your product?

Send an Email Call (804) 550-7143

Overview

The Schubert & Salzer Type 8049-ExPro is a compact digital positioner designed for use in hazardous area applications requiring intrinsic safety certification. Built for mounting on both linear and quarter-turn pneumatic actuators, the 8049-ExPro accepts a 4–20 mA control signal and features near-zero steady-state air consumption, making it well suited for process environments where air loss must be minimized.

Available in three Ex-rated variants — 8049-ExPro-0 (Zone 0/1/2), 8049-ExPro-1 (Zone 1/2), and 8049-ExPro-FM (FM-approved for North American installations) — the positioner carries ATEX and IECEx certifications and FM/CSA approvals. The “DeviceConfig” PC software enables full setup, calibration, and diagnostic access without opening the device in the field.

Features & Benefits

  • Intrinsically safe Ex ia IIC T4 rated — suitable for Zone 0, 1, and 2 hazardous locations (ATEX, IECEx, and FM/CSA certified versions available)
  • No steady-state air loss — stationary air consumption under 0.4 Nl/min, reducing operating costs and minimizing impact on air supply systems
  • Compatible with both linear and rotary (quarter-turn) actuators — single-acting and double-acting configurations supported
  • Self-adapting stroke and zero-point adjustment — reduces commissioning time with no manual calibration required
  • DeviceConfig PC software — provides setup, live monitoring, and diagnostic data including valve cycles, operating hours, stroke levels, and error history
  • IP 65 protection class — suitable for outdoor and washdown environments
  • Low vibration sensitivity — reliable performance in high-vibration industrial installations
  • Direct top-mount attachment to valve actuator — eliminates external stroke linkage and reduces mechanical complexity
  • Available in aluminum/polymer, stainless steel ground plate, or fully stainless steel body configurations
  • Optional feedback module RM-4 — provides 4–20 mA position feedback and two NAMUR limit signal transmitters

Technical Specifications

  • Control signal: 4–20 mA (intrinsically safe input)
  • Nominal stroke: 3–24 mm (linear); 0–90° (rotary)
  • Supply air max: 90 psi
  • Unrestricted air capacity: 24 Nl/min (at 73 psi pilot pressure)
  • Stationary air consumption: < 0.4 Nl/min
  • Leakage: < 0.01 Nl/min
  • Voltage of working resistance: 8 V (400 Ω @ 20 mA)
  • Ambient temperature: +14°F to +167°F (–10°C to +75°C)
  • Pressure supply port: G 1/8″ or NPT 1/8″
  • Max. connection section: 1.5 mm²
  • Protection class: IP 65 (per DIN 40050)
  • Air quality (ISO 8573-1): particle Class 3, oil Class 2, pressure dew point Class 3
  • Actuation gas: compressed air or non-flammable gases (nitrogen, CO₂)
  • Ex approvals — 8049-ExPro-1: II 2G Ex ia IIC T4 Gb / BVS 17 ATEX E 088
  • Ex approvals — 8049-ExPro-0: II 1G Ex ia IIC T4 Ga / BVS 17 ATEX E 088
  • Ex approvals — 8049-ExPro-FM: IS.CL.I, DIV.1, GP.A,B,C,D T4 entity / CL.I, Zone 0, AEx ia IIC T4 entity / FM22US0015 / FM22CA0010
  • Housing materials: Vestamid (electroconductive) body; aluminum (KTL-coated), stainless steel, or fully stainless steel ground plate options

Applications

  • Hazardous area process control requiring ATEX Zone 0/1/2 or FM Division 1 intrinsic safety certification
  • Chemical and petrochemical plants with flammable or explosive atmospheres
  • Oil & gas production and processing facilities
  • Offshore and marine installations
  • Hydrogen and specialty gas handling systems
  • Pharmaceutical and fine chemical manufacturing in classified areas
  • Pneumatic control valve positioning on linear globe valves and quarter-turn ball or butterfly valves

Type 8049-ExPro Accessories

  • RM-4 Feedback Module – Analog 4–20 mA position feedback module for 2-wire and ExPro versions; includes two freely adjustable NAMUR limit signal transmitters (0–100% range via DeviceConfig software)
  • Gauge Block – Installs between positioner and connection block; pressure range 0–87 psi (0–6 bar); field-retrofittable
  • Optical Position Indicator – Visual position indication for quarter-turn actuators; available with standardized mounting kits
