HTS Hauck – Ignition Gas Pilots IPG

Overview

The Honeywell Hauck IPG is a factory assembled, prepiped ignition gas pilot unit engineered for fast, straightforward installation. Available in three sizes (IPG-411, IPG-412, and IPG-413), the IPG provides a reliable means of lighting Hauck burners and many other makes of gas and oil burners across a wide range of industrial firing applications.

Each IPG is designed to deliver flame stability and extended service life under severe operating conditions, including automatic compensation for burner and furnace back pressure. The IPG capacity range spans 16,000 to 84,000 Btu/hr (4.2 to 22.2 kW) and is suitable for neutral, negative, and positive pressure applications.

Features & Benefits

• Factory prepiped and assembled using industry-accepted components — simplifies system integration and reduces installation time
• Back-loaded fuel gas regulator automatically compensates for variations in burner or furnace back pressure — maintains consistent air/fuel ratio without manual adjustment
• Air/gas mixer with finite fuel gas adjustment valve — allows precise mixture tuning for stable ignition
• Heat-resistant stainless steel alloy flame holder and nozzle — built for long service life under high-temperature and severe operating conditions
• Available in a manifold version with safety shutoff and leak test valves — simplifies compliance with insurance approval and NFPA code testing requirements
• Compatible with neutral, negative, and positive pressure furnace applications — broad installation flexibility
• Three pilot sizes available to match a range of firing capacities from 16,000 to 84,000 Btu/hr (4.2 to 22.2 kW)

Technical Specifications

• Capacity: 16,000 to 84,000 Btu/hr (4.2 to 22.2 kW)
• Gas supply pressure: 13.9 to 27.7 in. w.c.
• Air supply pressure range: 14 to 55 in. w.c.
• Ignition type: Electric spark
• Ignition transformer: 5,000/6,000 V coil type
• Spark plug gap — Size 1: 1/8 to 1/4 in. (3.2 to 6.4 mm); Sizes 2 & 3: 3/32 to 1/8 in. (2.4 to 3.2 mm)
• Flame length: approximately 150–230 mm (size dependent)
• Pilot nozzle position: slightly behind burner nozzle discharge
• Fuel type: Natural gas (other gaseous fuels — consult Hauck)
• Material: Stainless steel flame holder and nozzle
• Pressure application: Neutral, negative, and positive
• Pilot components: Gas regulator, air ball valve, gas ball valve, mixer, pilot nozzle, union, flex nipple

Applications

• Ignition of Hauck gas and oil burners in industrial furnace and combustion systems
• Ignition of many other makes of gas and oil burners where a prepiped pilot unit is required
• Positive, neutral, and negative pressure combustion chambers
• Industrial process heating applications requiring reliable, repeatable ignition under varying back pressure conditions
• Applications requiring NFPA code compliance with optional manifold safety shutoff and leak test valve configuration

Models / Configurations

• IPG-411 – Size 1 ignition gas pilot; spark plug gap 1/8 to 1/4 in. (3.2 to 6.4 mm)
• IPG-412 – Size 2 ignition gas pilot; spark plug gap 3/32 to 1/8 in. (2.4 to 3.2 mm)
• IPG-413 – Size 3 ignition gas pilot; spark plug gap 3/32 to 1/8 in. (2.4 to 3.2 mm)
• Manifold Version – Includes safety shutoff and leak test valves for NFPA code compliance and simplified insurance approval

IPG Ignition Gas Pilots Accessories

• IPG Spark Igniters – Replacement spark igniter assemblies for IPG pilot burners; refer to spare parts documentation for applicable part numbers by size
