Schubert & Salzer – Type 7332 Compact Flanged Motor Valve

Overview

The Schubert & Salzer Type 7332 is a compact integrally flanged motor valve engineered for precision on/off and modulating control in critical applications requiring greater pressure and high actuator thrust. Available in sizes 1/2″ to 3″ in stainless steel CF8M (316L body) with ANSI #150 (per ANSI B16.5) and DIN EN 1092-1 flange connections, the Type 7332 is rated to 580 psi. Media temperatures range from -22°F to 392°F with application capability up to 428°F.

Sharing the same high-thrust actuator platform as the Type 7310, the Type 7332 provides thrust options of 450 lbf and 1,120 lbf — far exceeding the 180 lbf of the compact motor valve family — with IP67 protection for demanding environments. Motor voltages of 24 V AC/DC, 230 V, and 110/120 V are supported with 3-point, (0)2–10V, and (0)4–20mA control signals. A fail-safe option is available on all control actuators.

Features & Benefits

• Compact integrally flanged body with ANSI #150 (ANSI B16.5) and DIN EN 1092-1 flange connections for direct installation in critical flanged piping systems
• Stainless steel CF8M (316L) body rated to 580 psi for demanding process media service
• High-thrust actuator options of 450 lbf and 1,120 lbf for reliable operation under high differential pressure conditions
• IP67 protection rating for use in submerged or high-washdown environments
• Fail-safe option available on all control actuators for defined valve position on power loss
• Available in sizes 1/2″ to 2″ with ANSI #150 and DIN EN 1092-1 flange support
• Motor voltage options: 24 V AC/DC, 230 V, and 110/120 V with 3-point, (0)2–10V, and (0)4–20mA control signal inputs
• Media temperatures from -22°F to 392°F with application capability up to 428°F
• Special versions available: pressure balanced, degreased, silicone-free, and PTFE-free
• Positioner electronics, limit switch, and position feedback accessories available
• CRN Certificate, EC and UKCA Declarations of Conformity available

Technical Specifications

• Size: 1/2″ – 3″
• Pressure: 580 psi; ANSI #150
• Body material: Stainless steel CF8M (316L)
• Media temperature: -22°F to 392°F
• Application temperature: up to 428°F
• Actuator type: Electric motor
• Actuator thrust: 450 lbf; 1,120 lbf
• Motor voltages: 24 V AC/DC; 230 V; 110/120 V
• Control signals: 3-point; (0)2–10V; (0)4–20mA
• Fail-safe: Option available on all control actuators
• Protection class: IP67
• Connection: Integral flange per DIN EN 1092-1; Integral flange per ANSI #150 (ANSI B16.5)
• Media compatibility: Gases, vapors, fluids
• Approvals & Certificates: CRN Certificate, EC Declaration of Conformity, UKCA Declaration of Conformity

Applications

• Precision on/off and modulating control in critical flanged pipeline applications requiring high actuator thrust
• ANSI #150 or DIN EN 1092-1 flanged process piping where high differential pressure demands 450 lbf or 1,120 lbf thrust
• Submerged or high-washdown environments requiring IP67 actuator protection
• Fail-safe applications requiring defined valve position on power loss
• Flanged installations where the standard 180 lbf compact motor valve family is insufficient
• Clean-service applications requiring degreased, silicone-free, or PTFE-free construction
• Applications requiring CRN certification for Canadian pressure vessel and piping compliance

Type 7332 Accessories

• Positioner Electronics – Optional integrated positioner electronics for enhanced modulating control capability with the Type 7332 motor actuator.
• Limit Switch – Position feedback accessory providing open/close status signal for process monitoring and control system integration.
• Position Feedback – Analog or digital position feedback device for continuous valve position monitoring and control system integration.
• Fail-Safe Actuator – Fail-safe option available on all control actuator configurations, providing defined valve position on power loss.
