Schubert & Salzer – Type 7310 Angle Seat Motor Valve

Overview

The Schubert & Salzer Type 7310 is a high-thrust angle seat motor valve engineered for precision on/off and modulating control in critical applications requiring greater pressure and thrust capability. Available in sizes 1-1/2″ to 3″ in stainless steel CF8M and rated to 580 psi, the Type 7310 features actuator thrust options of 450 lbf and 1,120 lbf — significantly higher than other motor valves in the Schubert & Salzer lineup — and is rated IP67 for enhanced environmental protection.

Media temperatures range from -22°F to 392°F with application capability up to 428°F. Connection options include NPT thread, Whitworth pipe thread, welding ends, and Tri-clamp. Motor voltages of 24 V AC/DC, 230 V, and 110/120 V are supported with 3-point, (0)2–10V, and (0)4–20mA control signals. A fail-safe option is available on all control actuators.

Features & Benefits

• High-thrust actuator options of 450 lbf and 1,120 lbf for reliable operation in critical, high-differential-pressure applications
• IP67 protection rating — higher ingress protection than the IP65-rated motor valves in the lineup, suited for submerged or high-washdown environments
• Stainless steel CF8M body rated to 580 psi for demanding process media
• Fail-safe option available on all control actuators for defined valve position on power loss
• Larger size range of 1-1/2″ to 3″ — targeted at bigger pipeline installations where higher thrust is needed
• Motor voltage options: 24 V AC/DC, 230 V, and 110/120 V with 3-point, (0)2–10V, and (0)4–20mA control signal inputs
• Broad connection options: NPT thread, Whitworth pipe thread, welding ends, and Tri-clamp for diverse installation requirements
• Media temperatures from -22°F to 392°F with application capability up to 428°F
• Special versions available: pressure balanced, degreased, silicone-free, and PTFE-free
• Positioner electronics, limit switch, and position feedback accessories available
• EC and UKCA Declarations of Conformity available

Technical Specifications

• Size: 1-1/2″ – 3″
• Pressure: 580 psi
• Body material: Stainless steel CF8M
• Media temperature: -22°F to 392°F
• Application temperature: up to 428°F
• Actuator type: Electric motor
• Actuator thrust: 450 lbf; 1,120 lbf
• Motor voltages: 24 V AC/DC; 230 V; 110/120 V
• Control signals: 3-point; (0)2–10V; (0)4–20mA
• Fail-safe: Option available on all control actuators
• Protection class: IP67
• Connection: NPT thread; Whitworth pipe thread; Welding ends; Tri-clamp
• Media compatibility: Gases, vapors, fluids
• Approvals & Certificates: EC Declaration of Conformity, UKCA Declaration of Conformity

Applications

• Precision on/off and modulating control in critical applications requiring high actuator thrust and greater pressure capability
• Large-diameter pipeline control in 1-1/2″ to 3″ sizes where standard 180 lbf motor valves are insufficient
• High-differential-pressure process applications requiring 450 lbf or 1,120 lbf actuator thrust
• Submerged or high-washdown environments requiring IP67 actuator protection
• Hygienic and sanitary process control (Tri-clamp connection version)
• Welded stainless piping systems requiring welding end connections
• Fail-safe applications requiring defined valve position on power loss
• Clean-service applications requiring degreased, silicone-free, or PTFE-free construction

Type 7310 Accessories

• Positioner Electronics – Optional integrated positioner electronics for enhanced modulating control capability with the Type 7310 motor actuator.
• Limit Switch – Position feedback accessory providing open/close status signal for process monitoring and control system integration.
• Position Feedback – Analog or digital position feedback device for continuous valve position monitoring and control system integration.
• Fail-Safe Actuator – Fail-safe option available on all control actuator configurations, providing defined valve position on power loss.
