Schubert & Salzer – Type 7033 Pad Mounted Valve for Valve Block

Overview

The Schubert & Salzer Type 7033 is a pneumatically operated stainless steel pad-mounted valve designed for safe shut-off of normal and aggressive media in valve manifold block installations. Available in sizes 3/8″, 1/2″, 3/4″, and 1-1/4″, the Type 7033 mounts directly onto valve blocks, eliminating the need for pipe fittings and reducing potential leak points in compact process assemblies.

Rated to PN 40 with a stainless steel CF8M body, the Type 7033 handles gases, vapors, and liquids across a media temperature range of -22°F to +392°F, with extended application capability from -148°F to +428°F. Multiple actuator options and special versions — including low temperature, pressure balanced, degreased, silicone-free, and PTFE-free — are available for demanding service conditions.

Features & Benefits

• Pad-mounting connection eliminates pipe fittings at the valve block interface, reducing assembly complexity and potential leak points
• Compact size range of 3/8″, 1/2″, 3/4″, and 1-1/4″ for use in space-constrained valve manifold assemblies
• Stainless steel CF8M body for compatibility with normal to aggressive media including gases, vapors, and liquids
• Rated to PN 40 with media temperatures from -22°F to +392°F
• Extended application temperature range of -148°F to +428°F for low-temperature and high-temperature service
• Pneumatically operated with choice of piston or stainless steel diaphragm actuator
• Actuator body options in brass (chrome plated), stainless steel, or polymer
• Optional ATEX non-electrical approval (II 2G Ex h IIC and II 2D Ex h IIIC) for hazardous area installations
• Special versions available: low temperature, pressure balanced, degreased, silicone-free, and PTFE-free
• Accessories including limit switch, pilot valve, manual override, and stroke limiter available from factory
• EC and UKCA Declarations of Conformity available

Technical Specifications

• Size: 3/8″, 1/2″, 3/4″, 1-1/4″
• Pressure: PN 40
• Body material: Stainless steel CF8M
• Media temperature: -22°F to +392°F
• Application temperature range: -148°F to +428°F
• Actuator types: Piston actuator (brass chrome plated, stainless steel, or polymer); Stainless steel diaphragm actuator
• Connection: Pad-mounting on valve manifolds
• Media compatibility: Gases, vapors, liquids
• ATEX (optional): II 2G Ex h IIC T6…T2 X Gb; II 2D Ex h IIIC 85°C…220°C X Db
• Approvals & Certificates: EC Declaration of Conformity, UKCA Declaration of Conformity

Applications

• On/off shut-off on valve manifold blocks in process instrumentation and control systems
• Compact multi-valve assemblies requiring direct pad-mount connection without pipe fittings
• Aggressive media isolation in chemical, petrochemical, and industrial process plants
• Low-temperature service applications (low-temperature version available)
• Clean-service applications requiring degreased, silicone-free, or PTFE-free construction
• Hazardous area installations requiring ATEX non-electrical approval

Type 7033 Accessories

• Limit Switch – Position feedback accessory providing open/close status signal for process monitoring and control integration.
• Pilot Valve – Solenoid pilot valve for pneumatic actuation control of the Type 7033 pad-mounted valve.
• Manual Override – Allows manual operation of the valve independent of pneumatic supply for maintenance or emergency use.
• Stroke Limitation – Adjustable stroke limiter for restricting valve travel to a defined partial-open position.
