HTS Maxon Direct Fired Furnace Burners – Kinemax
Need help selecting your product?
The Honeywell Eclipse KINEMAX series is a high-velocity, direct-fired burner system engineered for precise combustion control and exceptional flame stability across a wide range of process conditions. Designed for use in industrial furnaces, ovens, dryers, and other high-temperature applications, KINEMAX burners deliver uniform heat, low emissions, and excellent fuel efficiency with minimal maintenance.
Features & Benefits
- High-velocity combustion up to 275 ft/s for excellent temperature uniformity and heat transfer.
- Capacity range from 375,000 to 8,00,000 BTU/hr (110 – 2348 kW).
- Low NOx operation through advanced staged-air design and optimized combustion.
- Compact design suitable for retrofits or new installations.
- Operates efficiently with natural gas, propane, or mixed fuel gases.
- Wide turndown ratio up to 48:1 for stable performance at varying load demands.
- Optional pilot ignition, flame monitoring, and preheated air configurations.
Model Overview
| Model | Sizes | Typical Applications |
|---|---|---|
| KINEMAX | 1.5G, 2G, 3G, 4G, 6G | Industrial furnaces, ovens, dryers, and process heating systems |
Technical Specifications
| Parameter | Specification |
|---|---|
| Burner type | High-velocity direct-fired gas burner |
| Capacity range | 375,000 – 8,00,000 BTU/hr (110– 2348 kW) |
| Fuels | Natural gas, propane, or mixed gases |
| Turndown ratio | Up to 48:1 |
| Air supply | Ambient or preheated up to 600°F (315°C) |
| Emission performance | Low NOx (< 40 ppm typical) |
| Ignition options | Direct spark or pilot ignition |
| Flame monitoring | Ionization or UV sensor options |
Applications
- Industrial furnaces and ovens
- Continuous heat treatment and drying systems
- Air recirculating systems and process heaters
- Metals, glass, and ceramics processing
- Retrofit or new direct-fired burner installations
Documentation
Brochures / Docuthek
- Docuthek – KINEMAX Direct-Fired Burners (Honeywell Maxon)
Additional Information
For sizing, airflow, and control configuration support, please contact Martin Control & Equipment Company. All documentation and updates are available through the official Honeywell Thermal Solutions product page.
