HTS IFM – S55xBE(PF) Series Viewing Heads

Overview

The Honeywell S55xBE(PF) Series are single-channel UV, IR, and UV+IR combination viewing heads designed for industrial flame scanning applications. They must be used in conjunction with P522, P531, or P532 signal processors to form a complete flame monitoring system. Multiple sensor configurations provide flexibility across a wide range of fuel types and burner arrangements.

All S55xBE(PF) models feature electronic self-check (no mechanical shutter), an embedded temperature sensor, and a two-digit numeric display on the rear of the viewing head for real-time UV and IR flame count readout. Models are available in Turck connector or pipe fitting (PF) configurations and are mountable in any orientation.

Features & Benefits

• Multiple sensor options (UV+IR, IR only, UV only) provide application flexibility across varied fuel and burner types
• Electronic self-check on all models — no mechanical shutter required, reducing maintenance and failure points
• Two-digit numeric display on the rear of the viewing head shows live UV (green) and IR (red) flame counts without connecting to the signal processor
• Embedded temperature sensor allows internal temperature readings directly from the connected signal processor
• Adjustable UV gain (0–99) and IR gain (0–699) configurable remotely from the signal processor front panel
• Selectable IR flicker frequency filters (16 Hz, 24 Hz, 33 Hz, 52 Hz, 75 Hz, 100 Hz, 155 Hz, 215 Hz) optimize detection across fuel types
• Settings stored in EEPROM in the connected signal processor — retained through power loss and restored upon power-up
• Mountable in any orientation with 1 in. NPT female process connection and 1/2 in. NPT female purge air port
• Compatible with Honeywell FASA fiber optic extension products for high-temperature remote mounting applications
• SIL 3 “Fit for Use” rated in low demand safety applications

Technical Specifications

• Input Power: 24 VDC +10%, 100 mA (powered from Signal Processor)
• Transient Protection Requirement: Input voltage transients must be limited to 119 V maximum (required for IECEx approval)
• Operational Ambient Temperature: -40°F to 158°F (-40°C to 70°C)
• IECEx / CSA Ambient Temperature: -40°F to 149°F (-40°C to 65°C)
• Sealing: IP64
• Angle of View — IR Sensor: 1.0°
• Angle of View — UV Sensor: 3.0°
• UV Spectral Response: 190–215 nm
• Mounting: 1 in. NPT female; purge air: 1/2 in. NPT female
• Max Lens Pressure: 5 psi (isolation unit required above this level)
• Purge Air Requirement: ~0.13 Nm³/min (5 SCFM) delivered at 1 in. above maximum process pressure
• Approvals: CSA Class I, Division 2, Groups A, B, C, D, T5 — IECEx CSA 14.0036X Ex nA IIC T5 Gc IP64 — NCC/Inmetro NCC15.0076X Ex ec IIC T5 Gc IP64 — SIL 3 “Fit for Use” — KTL
• SIL Data — S550BE / S550BE-PF: SIL 3, HFT 0, PFD 1.98×10⁻⁴, SFF >99%
• SIL Data — S552BE / S552BE-PF: SIL 3, HFT 0, PFD 1.83×10⁻⁴, SFF >97.4%
• SIL Data — S556BE / S556BE-PF: SIL 3, HFT 0, PFD 1.93×10⁻⁴, SFF >99%
• Proof Test Interval: 1 to 5 years
• Signal Processor Compatibility: P522 (AC/DC), P531 (AC/DC), P532 (AC/DC)

Applications

• Industrial flame monitoring on single and multiple burner systems firing multiple fuels
• Natural gas and light oil flame detection
• Pulverized coal burner flame monitoring using IR flicker detection
• Low NOx burner applications requiring UV detection at the root of the flame
• Sulfur recovery unit (SRU) burners requiring dual-channel (UV+IR) discrimination
• Opposed-fired and multi-burner arrangements requiring per-burner flame discrimination
• Hazardous location installations — Class I, Division 2 rated environments
• High-temperature installations using fiber optic extension accessories
• SIL 3 safety instrumented system (SIS) applications in low demand mode

Models / Configurations

• S550BE – UV+IR combination viewing head with Turck connector; includes UV and IR sensors with dichroic beam-splitting mirror
• S550BE-PF – UV+IR combination viewing head with factory-installed 10 ft pigtail pipe fitting connection
• S550BE-PF-S – UV+IR combination viewing head with stub pipe fitting connection
• S552BE – IR-only viewing head with Turck connector; adjustable gain and flicker frequency filter
• S552BE-PF – IR-only viewing head with factory-installed 10 ft pigtail pipe fitting connection
• S556BE – UV-only viewing head with Turck connector; spectral response 190–215 nm
• S556BE-PF – UV-only viewing head with factory-installed 10 ft pigtail pipe fitting connection

S55xBE(PF) Series Accessories

• ASY55XBE – Pre-assembled over-molded connector with 50 ft C330S cable; IP64 rated with CIC/ITC approved cable — recommended for new installations
• ASY55XBE-200 – Pre-assembled over-molded connector with 200 ft C330S cable; IP64 rated with CIC/ITC approved cable
• C330S – ITC/CIC rated 4-conductor 22g foil/braid shielded cable with drain wire; sold per foot
• R-518-09 – Field-wireable replacement connector with insulating sleeve; accepts 10–12 mm cable (C328/C330); not recommended for new installations
• R-518-11 – Field-wireable replacement connector with insulating sleeve; accepts 6–8 mm cable (C330S); not recommended for new installations
• R-518-07 – Amphenol-Tuchel receptacle for S5xx series viewing heads
• LTA55XBE – Liquid tight viewing head cable adapter
• S5XXCR – Standard cable restraint for S5xx series
• S5XXCRLT – Liquid tight cable restraint for S5xx series
• R-518-12 – 1 in. NPT Ultem heat and electrical insulating nipple; used with swivel mounts or isolation units
• R-518-PT12 – 1 in. NPTM Ultem insulating locking coupler adapter for electrical and thermal isolation
• R-518-PT12L – 1 in. NPTM Ultem insulating locking coupler adapter with quartz lens
• R-518-CL12-HTG – Locking coupler; used with R-518-PT12 and R-518-PT12L adapters; 1 in. NPTF process connection
• R-518-CL12-PG – Locking coupler with 1/2 in. NPTF purge port; used with R-518-PT12 and R-518-PT12L adapters
• M-701-1, M-701-2, M-701-2-FLG, M-701-2-SS, M-701-3, M-701-3P, M-701-4 – Swivel mounts in various process connection configurations including 2 in. pipe slip-on, 2 in. NPTF, 2 in. flanged, stainless steel, and bolt-flange versions
• ISO-UNIT – Painted aluminum isolation unit with quartz window; 1 in. NPTF connections and 1/2 in. NPTF purge port
• ISO-UNITSS – Stainless steel isolation unit with quartz window; 1 in. NPTF connections and 1/2 in. NPTF purge port
• ISO-UNITHPGT – High-pressure isolation unit with 1/2 in. thick quartz window for elevated pressure applications
• M-702-6 – Orifice disk kit (3/8, 1/4, 3/16, and 1/8 in. diameter holes); used to reduce signal brightness in high-intensity flame applications
• M3204, M3208, M3210, M4025 – Vortex coolers for use with air cooling canister; contact factory for selection assistance
• S550FOAD, S550FOADY-FT, S550FOADY-FT-AL – Fiber optic extension adapters compatible with S55xBE viewing heads for high-temperature remote mounting
