HTS IFM – FASA Glass and Quartz Fiber Optics

Overview

The Honeywell FASA Glass and Quartz Fiber Optics series provides custom-engineered fiber optic extension assemblies designed to extend the optical path of UV, IR, or UV+IR flame detection viewing heads. FASA assemblies are ideally suited for applications where direct line-of-sight flame viewing is not possible, where ambient temperatures exceed the viewing head’s rated limit, or where the detector must be positioned closer to the flame for improved signal quality.

Two fiber optic material types are available: glass, for oil and coal flame monitoring applications, and quartz, for all fuel types including natural gas. Each FASA assembly is custom built for the specific installation and may include an outer carrier, inner carrier, and fiber optic bundle. Configurations may be fully flexible, flexible with a rigid section, or fully rigid with engineered adapters. All Honeywell signal processors and the U2 Series all-in-one viewing head are compatible with the FASA fiber optic system.

Features & Benefits

• Custom-engineered assemblies – Each FASA is adapted and built to the specific application requirements, ensuring proper fit and optimal flame sighting geometry.
• Two fiber optic material options – Glass fiber for oil and coal flame monitoring; quartz fiber for all fuel types, providing application-matched performance.
• Three-layer armored construction – Protected by a fiber optic cable, inner carrier, and outer carrier for reliable operation in high-vibration and high-temperature environments.
• Two lens assembly options – FOLC-SC provides a straight angle of view; FOLC-9C provides a 9-degree skewed viewing angle for offset sighting requirements.
• Flexible mounting configurations – Available as fully flexible, flexible with rigid section, or all-rigid assemblies with engineered burner-end adapters.
• Multiple connection adapters – Adapters available at the viewing head end for 1/2 NPT or 1 NPT connections, with or without air purge.
• Corrosion-resistant construction – Stainless steel materials provide corrosion protection in demanding combustion environments.
• Broad viewing head compatibility – Compatible with all Honeywell signal processors and the U2 Series all-in-one viewing head.

Technical Specifications

• Fiber optic types: Glass (oil and coal applications); Quartz (all fuel types)
• Detection spectrum: UV, IR, or UV+IR — dependent on paired viewing head
• Lens assemblies: FOLC-SC (straight angle); FOLC-9C (9-degree skewed angle)
• Viewing head end connections: 1/2 NPT or 1 NPT adapters (with or without air purge)
• Assembly configurations: Fully flexible; flexible with rigid section; all-rigid
• Transmission length: Application dependent — specified at time of order
• Construction material: Corrosion-protected stainless steel
• Compatible signal processors: All Honeywell signal processors; U2 Series all-in-one viewing head

Applications

• Industrial burner flame monitoring where direct viewing head placement is not feasible due to physical obstructions or limited access
• High-temperature combustion chambers where ambient temperatures exceed the viewing head’s rated operating limit
• Oil- and coal-fired burner applications requiring infrared (IR) flame detection via glass fiber optics
• Gas and multi-fuel burner applications requiring ultraviolet (UV) flame detection via quartz fiber optics
• Applications requiring offset or angled flame sighting using the FOLC-9C 9-degree lens assembly
• Industrial process heaters, boilers, and furnaces with restricted burner access points

Models / Configurations

• FASA – Fiber Optic Viewing Head Extension Assembly (standard)
• FASA-INT – Fiber Optic Internal Extension Assembly
• FOLC-SC – Fiber Optic Lens Cartridge / Coupler, straight angle of view
• FOLC-9C – Fiber Optic Lens Cartridge / Coupler, 9-degree skewed viewing angle
• FOLC-HS – Fiber Optic Lens Cartridge with 1/2 NPT connection
• S550FOAD – Fiber Optics for S55XB / S55XBE viewing heads
• S550FOADY-FT – Fiber Optics with air purge for S55XB / S55XBE viewing heads
• S592-PC – Fiber Assembly with quartz lens for S592 / S593 viewing heads
• S592-PP – Plano/plano window for S592 / S593 viewing heads
• 50107568-001 – Fiber Optic Adapter Body Lens

FASA Fiber Optics Accessories

The FASA system is compatible with Honeywell signal processors and the U2 Series viewing head. Air purge adapters and NPT connection adapters are available at the burner viewing end. Contact us to specify the correct assembly configuration, lens type, material, and transmission length for your application.

• FOLC-SC – Straight angle lens cartridge / coupler for standard direct-view installations
• FOLC-9C – 9-degree offset lens cartridge / coupler for skewed sighting angle applications
• FOLC-HS – 1/2 NPT connection fiber optic lens cartridge
• S550FOADY-FT – Air purge fiber optic assembly for S55XB / S55XBE viewing heads
