HTS Eclipse Butterfly Valves – BV-PAK
Need help selecting your product?
The Honeywell Eclipse BV-Pak is a preassembled butterfly valve and actuator package designed for precision control of combustion air and fuel delivery. Combining the Eclipse butterfly valve with the Honeywell Kromschröder IC-series actuator, this compact unit delivers reliable, repeatable modulation and simplified installation for industrial burner systems.
Features & Benefits
- Factory-mounted valve and actuator—saves installation time and ensures compatibility.
- Integrated position indicator for clear visual feedback.
- Rugged, industrial-grade design suitable for continuous-duty operation.
- Available in a wide range of valve sizes for various burner capacities.
- Ideal for air or gas control in combustion applications requiring precision modulation.
Model Overview
| Model | Valve Size | Description |
|---|---|---|
| BVP02 | ½″ | Butterfly Valve with IC Actuator Assembly, ½-inch |
| BVP03 | ¾″ | Butterfly Valve with IC Actuator Assembly, ¾-inch |
| BVP04 | 1″ | Butterfly Valve with IC Actuator Assembly, 1-inch |
| BVP05 | 1¼″ | Butterfly Valve with IC Actuator Assembly, 1¼-inch |
| BVP06 | 1½″ | Butterfly Valve with IC Actuator Assembly, 1½-inch |
| BVP08 | 2″ | Butterfly Valve with IC Actuator Assembly, 2-inch |
| BVP10 | 2½″ | Butterfly Valve with IC Actuator Assembly, 2½-inch |
| BVP12 | 3″ | Butterfly Valve with IC Actuator Assembly, 3-inch |
| BVP16 | 4″ | Butterfly Valve with IC Actuator Assembly, 4-inch |
Technical Specifications
- Valve Type: Eclipse butterfly valve (precision throttling type)
- Actuator Type: Kromschröder IC series or equivalent Honeywell actuator
- Sizes Available: ½″ through 4″
- Control Options: Modulating or On/Off operation (depending on actuator selection)
- Applications: Combustion air, fuel gas, and flue gas control
- Construction: Cast body with precision-machined disc and shaft assembly
Applications
The BV-Pak is ideal for systems requiring accurate control of air or gas flow in combustion processes, including:
- Industrial and commercial burners
- Heat treating furnaces and kilns
- Process heaters and ovens
- Power generation and thermal processing
Documentation
Honeywell Documentation
- Data Sheet – Product overview and assembly information
Additional Information
- Each BV-Pak assembly is factory-tested for performance and leak integrity.
- Available with various torque ratings and control interfaces to match application requirements.
- For selection or replacement assistance, contact Martin Control.
