HTS Eclipse – RatioStar Duct Burner

Overview

The Eclipse RatioStar is a modular duct burner engineered for on-ratio combustion control in direct-fired air heating applications. Burner modules are arranged in rows of up to 24 units, with propagation modules connecting individual rows to provide cross ignition across the full burner matrix. This modular architecture allows for a wide range of burner configurations to match duct geometry and heat release requirements.

Constructed of high-quality stainless steel, the RatioStar is built for demanding process environments including high-temperature inlet airflows up to 1400°F (750°C) where standard air heating burners cannot be used. Eclipse engineers can design a complete RatioStar duct system with integrated gas train to meet specific customer requirements.

Features & Benefits

• Modular design — rows of up to 24 burner modules allow flexible matrix configurations to fit virtually any duct size or shape
• On-ratio combustion control maintains optimum air/fuel ratio across the full firing range for consistent combustion efficiency
• Propagation modules provide cross ignition between burner rows for reliable, uniform light-off across the entire matrix
• High-temperature capability — handles process inlet air temperatures up to 1400°F (750°C) where conventional air heating burners are not suitable
• Low oxygen process compatibility — suitable for airflows with reduced oxygen levels requiring supplemental heat
• Stainless steel construction for durability in high-temperature, corrosive, or demanding industrial environments
• Custom-engineered systems available — Eclipse engineers design complete duct burner systems with gas train to customer specifications

Technical Specifications

• Burner type: Modular on-ratio duct burner
• Module row capacity: Up to 24 modules per row
• Maximum inlet air temperature: 1400°F (750°C)
• Construction: High-quality stainless steel
• Ignition: Cross ignition via propagation modules
• Control: On-ratio combustion control
• System configuration: Custom-engineered gas train and burner matrix available

Applications

• Air heating processes requiring optimum heat distribution across process airflows
• Air heating processes requiring optimum combustion efficiency through on-ratio control
• Low-oxygen process airflows that require supplemental heat addition
• High-temperature inlet airflow processes up to 1400°F (750°C) where standard air heating burners cannot be used
• Industrial drying and curing ovens
• Thermal oxidizers and afterburners
• Heat treat and process furnaces with duct-style air heating

Models / Configurations

• Standard Burner Module – Individual on-ratio duct burner module; assembled in rows of up to 24 modules to form the burner matrix
• Propagation Module – Connects individual burner rows to provide cross ignition across multi-row burner matrix configurations
• Custom Matrix Configuration – Complete RatioStar duct burner system with gas train, engineered to customer-specified duct geometry and heat release requirements

RatioStar Accessories

• Integrated Gas Train – Custom-configured gas supply and control train engineered by Eclipse to match the specific RatioStar system design and application requirements
