The Honeywell Eclipse ExtensoHeat burner series is designed for high-efficiency, direct-fired process heating applications that demand exceptional temperature uniformity, extended heat coverage, and reduced emissions. Its unique burner design allows for a long, stable flame and wide-area heating, making it ideal for large furnaces, ovens, and dryers requiring even thermal distribution.
Features & Benefits
- Provides extended flame length for uniform heat coverage across large process zones.
- High combustion efficiency with stable operation over a wide turndown range.
- Supports both natural gas and propane operation.
- Capacities available up to 500,000 BTU/hr (146 kW) depending on configuration.
- Compact and modular construction simplifies installation and maintenance.
- Suitable for continuous or intermittent operation in direct-fired heating systems.
Model Overview
| Model | Configuration | Typical Applications |
|---|---|---|
| ExtensoHeat | Long-flame direct-fired burner with adjustable air/fuel mixing | Industrial furnaces, ovens, and process dryers requiring extended heating zones |
Technical Specifications
| Parameter | Specification |
|---|---|
| Burner type | Direct-fired long-flame gas burner |
| Capacity range | 85,000 – 500,000 BTU/hr (25 – 146 kW) |
| Fuels | Natural gas or propane |
| Max Furnace temperature | 1832°F (1000°C) |
| Flame length | Adjustable; extended flame for even temperature profile |
Applications
- Industrial furnaces and ovens requiring long, stable flames
- Large dryers, kilns, and process heating lines
- Continuous heat treatment and preheating processes
Documentation
Brochures / Docuthek
- Docuthek – ExtensoHeat Direct-Fired Burners (Honeywell Eclipse)
Additional Information
For assistance with flame configuration, system integration, or sizing support, please contact Martin Control & Equipment Company. All documentation and updates are available through the official Honeywell Thermal Solutions product page.
